776164-1 AMP TE Connectors 35pin
| Product name | Connectors |
| Parts number | 776164-1 |
| Number of Positions: | 35 Position |
| Pitch: | 4 mm |
| Gender: | Receptacle (Female) |
| Mounting Style: | Cable Mount / Free Hanging |
| Termination Style: | Crimp |
| Wire Gauge Min: | 20 AWG |
| Wire Gauge Max: | 16 AWG |
| Color: | Black |
| Application: | Power, Signal |
| Attachment Hole Diameter: | 1.3 mm |
| Brand: | TE Connectivity |
| Contact Gender: | Without Socket Contacts |
| Contact Type: | Socket |
| Current Rating: | 17 A |
| Description/Function: | AMPSEAL, Automotive Terminals |
| Flammability Rating: | UL 94 V-0 |
| Height: | 34.6 mm |
| Ingress Protection: | IP6K9K |
| Length: | 63.4 mm |
| Lock Mate Feature: | Integrated in Housing |
| Material: | Plastic |
| Maximum Operating Temperature: | + 125 C |
| Minimum Operating Temperature: | - 40 C |
| Mounting Angle: | Straight |
| Number of Rows: | 3 Row |
| Product Type: | Automotive Connectors |
| Row Spacing: | 4 mm |
| Subcategory: | Automotive Connectors |
| Voltage Rating: | 250 VAC |
| Width: | 33.6 mm |
| Wire Gauge Range: | 16 AWG to 20 AWG |
| Unit Weight: | 33 g |
